OV11HO-2FO-100
▶2xLC Fiber
▶MM mode
▶Length: 300M
Features
1.Can work in single fiber mode when only need HDMI signal from TX to RX;
2.Dual fiber mode for full function extender which suupport all communication between TX and RX;
3.Support bi-directional IR, RS232;
4.Support 18Gbps video bandwidth HDMI2.0b, HDCP 2.3, video resoution can reach up to 4K@60HZ 4:4:4;
5.Support 300 meters multi-mode OM3 fiber;
6.Support HDR10 and HDR10+;
7.Audio formats support Dolby Atoms, TrueHD, Digital+, Digital, DTS X, HD Master Audio, HD High Resolution Audio 5.1, PCM 2-8CH;
8.The receiver can be powered by TV USB port;
9.High performance and low cost brought about by technological innovation;
Specifications
| Transmiter | Input: HDMI Output: LC fiber (AV),LC fiber (AUX) Control Signal: IR IN, IR OUT, RS232 Power: USB-C |
| Receiver | Input: LC fiber (AV),LC fiber (AUX) Output: HDMI Control Signal: IR IN, IR OUT, RS232 Power: USB-C |
| Optical Fiber | OM3 Multi-mode LC fiber |
| Video Bandwith | 18Gbps |
| Max Support Video Resolution | 4K@60HZ(4096x2160) |
| Color Space | RGB, YUV4:4:4, YUV4:2:2, YUV4:2:0 |
| Max Support Color Depth | 36bit Deep Color |
| HDR | HDR 10, HDR 10+, Dolby Vision |
| EDID Compatible | YES |
| HDCP | 2.3 |
| Maximum Transmission Distance | 300M |
| Audio Format | Dolby Atmos, Dolby True HD, Dolby Digital+, Digital, DTS HD, DTS X, HD Master Audio, HD High Resolution Audio, LPCM7.1, |
Download datasheet:
OV11HO-2FO-100 V1.1.pdf
